Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | CCT |
|---|---|---|---|---|---|---|
| SL0054H 417 mm | 13 W | 97 CRI | 24 V DC | 1040 lm | H417 mm; head Ø120 mm; ground spike Ø50 × 210 mm | 2700, 3000, 4000 K |
| SL0058H 617 mm | 13 W | 97 CRI | 24 V DC | 1040 lm | H617 mm; head Ø120 mm; ground spike Ø50 × 210 mm | 2700, 3000, 4000 K |
| SL0062H 817 mm | 13 W | 97 CRI | 24 V DC | 1040 lm | H817 mm; head Ø120 mm; ground spike Ø50 × 210 mm | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Mounting
- Wall, Floor
- IP rating
- IP65
- Certifications
- CE
Photometry
SL0054. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 13 W
- Luminous flux
- 1,040 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 331 cd
- Field angle (10%)
- 168.5°
- At 3 m
- 37 lx, Ø10.39 m
