Technical specifications
| Code | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|
| DL1992 | 97 CRI | max 36 V | 2*630 lm | L132 x W49 x H67 mm | 34° 48° | 2700, 3000, 4000 K | Ø85 mm | 350 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 34°, 48°
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
Photometry
DL1992. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Luminous flux
- 2 lm
- Peak intensity
- 5 cd
- Field angle (10%)
- 62°
- At 3 m
- 1 lx, Ø1.83 m
- Luminous flux
- 2 lm
- Peak intensity
- 3 cd
- Field angle (10%)
- 87.5°
- At 3 m
- 0 lx, Ø2.67 m
