Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|---|
| DL1934 | 7 W | 97 CRI | max 20 V | 560 lm | L145 x W41 x H49 mm | 24° 38° | 2700, 3000, 4000 K | Ø91 mm | 350 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 24°, 38°
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
Photometry
DL1934. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 7 W
- Luminous flux
- 560 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 2,847 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 316 lx, Ø1.28 m
- Power
- 7 W
- Luminous flux
- 560 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 1,154 cd
- Field angle (10%)
- 69.3°
- At 3 m
- 128 lx, Ø2.07 m
