Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|---|
| DL1645 | 10 W | 97 CRI | max 32 V | 960 lm | L199 x W41 x H60 mm | 90° | 2700, 3000, 4000 K | Ø143 mm | 300 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 90°
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
Photometry
DL1645. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 10 W
- Luminous flux
- 960 lm
- Efficacy
- 96 lm/W
- Peak intensity
- 413 cd
- Field angle (10%)
- 164°
- At 3 m
- 46 lx, Ø6.00 m
