Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|---|
| DL0753 | 22 W | 97 CRI | 4 × max 37 V | 2200 lm | L208 x W62 x H68 mm | 15° 30° 45° | 2700, 3000, 4000 K | Ø202 mm | 600 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 15°, 30°, 45°
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
Photometry
DL0753. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 22 W
- Luminous flux
- 2,200 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 28,445 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 3,161 lx, Ø0.79 m
- Power
- 22 W
- Luminous flux
- 2,200 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 7,200 cd
- Field angle (10%)
- 54.7°
- At 3 m
- 800 lx, Ø1.61 m
- Power
- 22 W
- Luminous flux
- 2,200 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 3,266 cd
- Field angle (10%)
- 82°
- At 3 m
- 363 lx, Ø2.49 m
