Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|
| S3-4833Track | 10 W | 97 CRI | 520–580 lm | 44 × 135 mm | 20° 35° | 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 20°, 35°
- Control
- Triac, DALI-2, 0–10 V
- Mounting
- Magnetic track, Recessed
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
S3-4833. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 10 W
- Luminous flux
- 520 lm
- Efficacy
- 52 lm/W
- Peak intensity
- 3,794 cd
- Field angle (10%)
- 36.5°
- At 3 m
- 422 lx, Ø1.06 m
- Power
- 10 W
- Luminous flux
- 520 lm
- Efficacy
- 52 lm/W
- Peak intensity
- 1,258 cd
- Field angle (10%)
- 63.8°
- At 3 m
- 140 lx, Ø1.89 m
