Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|
| P3-3220HPendant | 40 W | 97 CRI | 3800–4100 lm | L1200 x W25 x H85 mm | 20° 40° 60° 80° | 3000, 4000 K |
| C3-3220HSurface mounted | 40 W | 97 CRI | 3800–4100 lm | — | 20° 40° 60° 80° | 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 20°, 40°, 60°, 80°
- Control
- Triac, Casambi, DALI, 0–10 V
- Mounting
- Surface, Suspended
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
P3-3220H. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 40 W
- Luminous flux
- 3,800 lm
- Efficacy
- 95 lm/W
- Peak intensity
- 27,726 cd
- Field angle (10%)
- 36.5°
- At 3 m
- 3,081 lx, Ø1.06 m
- Power
- 40 W
- Luminous flux
- 3,800 lm
- Efficacy
- 95 lm/W
- Peak intensity
- 7,085 cd
- Field angle (10%)
- 72.9°
- At 3 m
- 787 lx, Ø2.18 m
- Power
- 40 W
- Luminous flux
- 3,800 lm
- Efficacy
- 95 lm/W
- Peak intensity
- 3,269 cd
- Field angle (10%)
- 109.4°
- At 3 m
- 363 lx, Ø3.46 m
- Power
- 40 W
- Luminous flux
- 3,800 lm
- Efficacy
- 95 lm/W
- Peak intensity
- 1,968 cd
- Field angle (10%)
- 145.8°
- At 3 m
- 219 lx, Ø5.04 m
